Bunk House Container

• Color
• Custom (Standard white/blue/green)

• Connection
• Welded/bolted

• Dimension (L*W*H)
• 6000mm x 3000mm x 2800mm

• Door
• Other, Standard Steel Security Door

• Door Material
• Other

• Earthquake Intensity
• 8 Grade

• Floor Load
• 250 kg/m2

• Floor Material
• Steel frame with waterproof plywood

• Insulation
• Other

• Life Span
• 15-20 Years

• Material
• Other

• Open Style
• Sliding

• Roof Dead Load
• 60 kg/m2

• Roof Live Load
• 30 kg/m2

• Roof Material
• Other

• Thickness Of Wall Panel
• 50 mm

• Use
• Other

• Wall Materials
• Other

• Window
• Other

• Window Material
• Other

• Window Style
• Other

• Color
• Blue (customizable)

• Connection
• Welded and bolted joints

• Dimension (L*W*H)
• 10ft x 10ft x 8.6ft

• Door
• Other, Single steel security door

• Door Material
• Other

• Earthquake Intensity
• 8 grade

• Floor Load
• 250 kg/m2

• Floor Material
• Cement board with vinyl flooring

• Insulation
• Other

• Life Span
• 15-20 years

• Material
• Other

• Open Style
• Other, Sliding windows, swing door

• Roof Dead Load
• 0.5 kN/m2

• Roof Live Load
• 0.3 kN/m2

• Roof Material
• Other

• Thickness Of Wall Panel
• 50mm

• Use
• Other

• Wall Materials
• Other

• Window
• Other

• Window Material
• Other

• Window Style
• Other

• Color
• Beige with Brown Border (Customizable)

• Connection
• Bolted & Welded Steel Frame Structure

• Dimension (L*W*H)
• 10 ft x 10 ft x 8.6 ft

• Door
• Other, Single Entry Door

• Door Material
• Other, Powder Coated Steel or Metal Panel Door

• Earthquake Intensity
• Designed for Zone IV & V

• Floor Load
• 250 kg/m2

• Floor Material
• PVC Vinyl Flooring

• Insulation
• Other, PUF or Glass Wool filled Panels

• Life Span
• 10-15 Years

• Material
• Other , MS Frame with Sandwich PUF Panels

• Open Style
• Other, Hinged Door, Sliding Window

• Roof Dead Load
• 40 kg/m2

• Roof Live Load
• 60-80 kg/m2

• Roof Material
• Other, MS (Mild Steel) Structure with Insulated Panel

• Thickness Of Wall Panel
• 50 mm to 75 mm

• Use
• Other, Portable Accommodation, Labor/Staff Housing, Site Office

• Wall Materials
• Other, Sandwich PUF/Steel Panel

• Window
• Other, 2 Units, Front & Side Placement

• Window Material
• Other, Aluminum Sliding Windows with Glass

• Window Style
• Other, Sliding

• Color
• Custom Wooden Finish/As per Request

• Connection
• Bolted & Welded Structure

• Dimension (L*W*H)
• 20x10x8.6 ft

• Door
• Other, Single Leaf

• Door Material
• Other, MS Sheet Door

• Earthquake Intensity
• Designed for Zone IV & V

• Floor Load
• 300 kg/m2

• Floor Material
• PVC Vinyl Flooring

• Insulation
• Other, PUF/Glass Wool Insulation

• Life Span
• 15-20 Years

• Material
• Other , Mild Steel (MS)

• Open Style
• Other, Hinged Door, Sliding Window

• Roof Dead Load
• 50 kg/m2

• Roof Live Load
• 75 kg/m2

• Roof Material
• Other, MS Sheet with Insulation

• Thickness Of Wall Panel
• 50 mm

• Use
• Other, Dormitory/Temporary Accommodation

• Wall Materials
• Other, Sandwich Panel/MS Sheet

• Window
• Other, Provision for Ventilation Windows

• Window Material
• Other, Aluminum/PVC Sliding Window

• Window Style
• Other, Sliding

• Color
• Beige/Light Cream (Customizable)

• Connection
• Welding and Mechanical Fasteners

• Dimension (L*W*H)
• 30 ft x 10 ft x 8.6 ft

• Door
• Other, 1 Main Door

• Door Material
• Other, MS Sheet with Insulation

• Earthquake Intensity
• Designed for Seismic Zone III-IV

• Floor Load
• 250 kg/m2 (approx)

• Floor Material
• Laminated Wooden/Bakelite Ply over MS Framework

• Insulation
• Other, Polyurethane Foam (PUF)

• Life Span
• 15-20 Years

• Material
• Other , Mild Steel (MS) Structural Frame

• Open Style
• Other, Sliding/Outward Hinged

• Roof Dead Load
• 0.5-1.0 kN/m2

• Roof Live Load
• 0.75 kN/m2

• Roof Material
• Other, Precoated Galvanized Iron Sheet

• Thickness Of Wall Panel
• 50 mm - 75 mm

• Use
• Other, Portable Accommodation/Bunk Bed Container

• Wall Materials
• Other, Insulated Sandwich PUF Panel/MS Sheet with Insulation

• Window
• Other, 2-4 Windows (Varies as per design)

• Window Material
• Other, Aluminum/UPVC Sliding Windows with Glass

• Window Style
• Sliding Window

• Color
• Wood Finish/Customizable

• Connection
• Welded and bolted connections

• Dimension (L*W*H)
• 40x10x8.6 feet (approximately 12.2x3.05x2.62 meters)

• Door
• Other, Standard Security Door

• Door Material
• Other, Metal Door with locking system

• Earthquake Intensity
• Designed for Intensity 8

• Floor Load
• 250 kg/m2

• Floor Material
• Wooden laminated board

• Insulation
• Other, PU foam/EPS insulation

• Life Span
• 15-20 years

• Material
• Other , Mild Steel (MS) Container

• Open Style
• Other, Sliding and Hinged

• Roof Dead Load
• 0.35 KN/m2

• Roof Live Load
• 0.5 KN/m2

• Roof Material
• Other, Mild Steel Sheet with Insulation

• Thickness Of Wall Panel
• 50-75 mm

• Use
• Other, Portable accommodation, labor camp, dormitory, site office

• Wall Materials
• Other, Sandwich panel (PU or EPS core), Mild Steel Sheet

• Window
• Other, Sliding Glass Window

• Window Material
• Other, Aluminium or uPVC framed glass

• Window Style
• Other, Sliding / Fixed

• Color
• Wooden Brown Interior, Exterior as per specification

• Connection
• Welded or Bolted

• Dimension (L*W*H)
• 10x12x8.6 ft

• Door
• Other, 1 Unit, Steel

• Door Material
• Other, Powder Coated Steel

• Earthquake Intensity
• Designed for moderate earthquake zones

• Floor Load
• 300 kg/m2

• Floor Material
• Laminated Wooden Flooring

• Insulation
• Other, PUF / Glass wool insulation

• Life Span
• 15-20 Years

• Material
• Other , Mild Steel Structure

• Open Style
• Other, Sliding/Outward

• Roof Dead Load
• 60 kg/m2

• Roof Live Load
• 60 kg/m2

• Roof Material
• Other, Mild Steel Sheets with Insulation

• Thickness Of Wall Panel
• 50 mm

• Use
• Other, Temporary Accommodation / Site Office / Workers Dormitory

• Wall Materials
• Other, Insulated Sandwich Panels / Mild Steel Panels

• Window
• Other, 2 Units, Sliding Glass

• Window Material
• Other, Aluminum or UPVC Sliding Windows with Glass

• Window Style
• Sliding Window

• Color
• Wooden Finish Interior, Standard Exterior Color (customizable)

• Connection
• Welded/bolted connections, Modular Assembly

• Dimension (L*W*H)
• 20ft x 12ft x 8.6ft (6096mm x 3657mm x 2620mm)

• Door
• Other, 1 Main Door

• Door Material
• Other, Powder-Coated Steel Door

• Earthquake Intensity
• Seismic Zone IV/V compliant

• Floor Load
• 300 kg/m2

• Floor Material
• PVC Vinyl Flooring

• Insulation
• Other, PUF/Glass Wool, Fire-Retardant

• Life Span
• 15-20 Years

• Material
• Other , Mild Steel (MS) Structural Frame

• Open Style
• Other, Sliding Windows, Hinged Door

• Roof Dead Load
• 50 kg/m2

• Roof Live Load
• 150 kg/m2

• Roof Material
• Other, Mild Steel Sheet with Insulation

• Thickness Of Wall Panel
• 50mm to 75mm

• Use
• Other, Accommodation, Site Office, Temporary Housing

• Wall Materials
• Other, Mild Steel Sandwich Panels with Insulation

• Window
• Other, 2-4 Sliding Windows (as per design)

• Window Material
• Other, Aluminium Sliding Window with Grills and Mosquito Net

• Window Style
• Other, Standard Sliding Style

• Color
• Custom/Beige & Brown

• Connection
• Bolted/Welded

• Dimension (L*W*H)
• 30ft x 12ft x 8.6ft

• Door
• Other, Single/Double

• Door Material
• Other, MS Powder Coated Door

• Earthquake Intensity
• Grade 8 resistant

• Floor Load
• 300 kg/m2

• Floor Material
• Vinyl/Marine Plywood

• Insulation
• Other, Rockwool/PUF

• Life Span
• 15-20 Years

• Material
• Other , Mild Steel (MS)

• Open Style
• Swing

• Roof Dead Load
• 80-120 kg/m2

• Roof Live Load
• 80-120 kg/m2

• Roof Material
• Other, MS Sheet with insulation

• Thickness Of Wall Panel
• 50mm to 75mm

• Use
• Other, Accommodation/Bunk Bed Sleeping Quarters

• Wall Materials
• Other, MS Sheet with Rockwool/PUF Insulation

• Window
• Other, 2-4 per Container

• Window Material
• Other, Aluminium/UPVC with Glass

• Window Style
• Other, Sliding

• Color
• As per Customer Requirement

• Connection
• Welded Bolted Connection

• Dimension (L*W*H)
• 40 ft x 12 ft x 8.6 ft (12192 x 3658 x 2621 mm)

• Door
• Other, Single/Double Leaf

• Door Material
• Other, Pre-coated Steel Door

• Earthquake Intensity
• Designed for Zone IV & V

• Floor Load
• 350 kg/m2

• Floor Material
• Vinyl/Plywood over Mild Steel Base

• Insulation
• Other, Polyurethane (PUF) / Glass Wool

• Life Span
• 15-20 Years (Approx.)

• Material
• Other , Mild Steel (MS)

• Open Style
• Other, Sliding / Hinged

• Roof Dead Load
• 85 kg/m2

• Roof Live Load
• 100 kg/m2

• Roof Material
• Other, Mild Steel Sheet with Insulation

• Thickness Of Wall Panel
• 50-75 mm

• Use
• Other, Accommodation / Labour Camp / Staff Housing

• Wall Materials
• Other, Sandwich Panel (Mild Steel / PUF Insulated)

• Window
• Other, Two per Container (Customizable)

• Window Material
• Other, Aluminum/UPVC Sliding Windows

• Window Style
• Other, Sliding
